| d | Bore diameter | 55.58 | mm |
| B | Width inner ring | 55.55 | mm |
| C | Width outer ring | 25 | mm |
| Da | Centering diameter | 113 | mm |
| L | Overall length | 140 | mm |
| A | Distance from the housing flange to the front of the inner ring of the bearing | 44.7 | mm |
| A1 | Width of the top of the housing | 4 | mm |
| J | Pitch circle diameter | 140 | mm |
| N | Diameter of attachment slot | 13.5 | mm |
| Fr | Radial load | 9.8 | kN |
| Fa | Axial load | 5.1 | kN |
| kg | Mass | 2.05 | kg |
| Cdyn | Dynamic load rating | 43.5 | kN |
| Co | Static load rating | 29 | kN |
| Pu | Fatigue load limit | 1.218 | kN |
